TOP SPEED
20 mph
RANGE
UP-TO 60 miles
MOTOR POWER
750 W
PAYLOAD
440 lbs
FOLDABLE
Not Foldable
BRAND WARRANTY
2-year
Cruise Control
Cruise Control lets you lock in your perfect pace with the push of a button. Whether you’re coasting through city streets or along open paths, it keeps your speed steady so you can focus on the ride, not the pedals.
Sensor Switch
Like two bikes in one, choose between a Torque or Cadence sensor with Sensor Switch. Whether you want a natural, responsive ride or a relaxed cruise, Aventon’s Sensor Switch gives you the flexibility to optimize your journey.
Integrated Kickstand Lock
The kickstand lock keeps your bike stable and secure by preventing it from being moved or rolled away while the kickstand is down—making it ideal for loading cargo or making quick stops during your daily routines.
Boost Mode
Available on all ACU-equipped, hub-driven ebike models, Boost Mode delivers up to 120% of specified torque and peak power for up to 30 seconds. It turns steep hills into shortcuts and makes heavy loads feel effortlessly light.
Geometry
| Frame Size | One Size Fits Most |
|---|---|
| A – Seat Tube Length | 380mm (15″) |
| B – Top Tube Length Horizontal | 610mm (24″) |
| C – Bottom Bracket Drop | 30mm (1″) |
| D – Head Tube Length | 210mm (8″) |
| E – Head Tube Angle | 69° |
| F – Seat Tube Angle | 70° |
| G – Rear Chainstay Length | 660mm (26″) |
| H – Front Wheel Center | 673mm (26″) |
| I – Wheelbase | 1332mm (52″) |
| J – Reach | 420mm (16″) |
| K – Stack Height | 521mm (20″) |
| L – Fork Length | 394.5mm (15″) |
| M – Fork Offset | 38mm (1″) |
| N – Trail | 63mm (2″) |
| Wheel Size in Inches | 20″ |
| Rider Height (Range) | 150cm – 198cm (4’11”-6’3″) |
Specs & Details
General Info
| Model | Abound LR Ebike |
| Weight | 88lbs |
| Total Weight Limit | 440 lbs |
| Rider Height | 4’11” – 6’3″ |
| Ebike Class | Class 2 Ebike |
| Range | Up to 60 miles |
| Battery Safety Certifications | Certified to UL 2271 |
| Safety Certifications | UL and TUV Safety Certified UL 2849 |
| Ideal Use | Cargo & Utility |
| Pedal Assist | 3 Levels (with Ride Tune Customization) |
| Carry Capacity | Carry Up To 2 Passengers |
| Water Resistance | Bike – IPX5 // Components – IPX6 |
Frameset
| Frame | Gravity Cast 6061 Single-Butted Aluminum Alloy with Internal Battery |
| Fork | Threaded Steerer Tube for Quill Stem 15×110 spacing, 51mm travel, adjustable lockout black stanchions |
| Rear Spacing | 175mm |
| Fork Spacing | 110mm |
| Frame Style | Step-Through |
Wheelset
| Front Wheel | Double Wall Aluminum, 20in, 36hole, 13g, 20×110 Thru Axle, Schrader Valve |
| Rear Wheel | Double Wall Aluminum, 20in, 36hole, 12g, Nutted Hub Drive Motor, Scharder Valve |
| Tires | 20×3.0 Innova IA-2131 Urban Tire Refective Sidewalls |
Ebike System
| Motor | Shengyi 36V 750w Hub Drive with 6 speed sensors (1188W peak) |
| Motor Torque | 80Nm |
| Display | Aventon BC147 |
| Battery | Removable Internal Lithium-ion. 36V, 20Ah, 733Wh, LG 21700 cells |
| Battery Weight | 8.7lbs |
| Controller | 36V/33A |
| Throttle | Aventon LH Handlebar Mounted |
| Sensors | Double Sided Bottom Bracket Torque Sensor |
| Charger | 36V Output: 42V/ 4A |
| Charging time from 0% to 100% | 5 hours |
| Lights | Front and Rear Lights Integrated w/ Turn Signals |
| Speed | Class 2 |
Brakes
| Front Brake | Tektro HD-E3520 hydraulic disc brakes w/ EJ1 quick disconnect wire |
| Rear Brake | Tektro HD-E3520 hydraulic disc brakes w/ EJ1 quick disconnect wire |
| Front Brake Rotor | 180mm 6 bolt |
| Rear Brake Rotor | 203mm 6-bolt |
Drivetrain
| Rear Derailleur | Shimano Altus RD-M310 8 Speed |
| Shifter | Shimano 8 Speed Trigger SL-M315-8R |
| Chain | 7/8 speed 154L |
| Cassette | 12-32T / 8 Speed Shimano CS HG200-8 |
| Chainring | 52 tooth |
| Crank | 3pc, 165mm crank arm |
| Bottom Bracket | Square Taper, Sealed, Dual-Sided Torque Sensor |
| Pedals | 9/16″ Composite Platform |
Cockpit
| Saddle | Aventon Saddle w/ grab handle by Selle Royal |
| Seatpost | Aventon Suspension Seatpost, Ø 30.9mm, 350mm Length. 50mm travel |
| Seatpost Clamp | 34.9mm |
| Handlebars | BMX Style Aluminum 31.8mm, 720mm |
| Grips | Aventon Ergonomic Comfort lock on grips |
| Headset | H886HW Peilin 28.6mm * 56mm * 56mm H19.5mm 6pcs |
Included Accessories
| Fenders | Included |
| Rear Rack | Included |
| Rear Rack Weight Limit | 143 lbs |
