TOP SPEED
20 mph
RANGE
UP-TO 60 miles
MOTOR POWER
750 W
PAYLOAD
440 lbs
FOLDABLE
Not Foldable
BRAND WARRANTY
2-year
Cruise Control
Cruise Control lets you lock in your perfect pace with the push of a button. Whether you’re cruising city streets or relaxing on open paths, it keeps your speed steady so you can focus on the ride, not the pedals.
Integrated Kickstand Lock
The integrated kickstand lock keeps your bike securely parked by preventing it from being moved or rolled away while the kickstand is down—perfect for loading cargo or making quick stops during your everyday adventures.
Sensor Switch
Like two bikes in one, you can choose between a Torque or Cadence sensor with Sensor Switch. Whether you want a responsive ride or a smooth cruise, the Sensor Switch lets you customize your cycling experience.
Boost Mode
Available on all ACU-equipped, hub-driven ebike models, Boost Mode delivers up to 120% of specified torque and peak power for up to 30 seconds. Sail up steep hills and tackle heavy loads with hassle-free, on-demand power.
Geometry
| Frame Size | One Size Fits Most |
|---|---|
| A – Seat Tube Length | 380mm (14″) |
| B – Top Tube Length Horizontal | 610mm (24″) |
| C – Bottom Bracket Drop | -30mm (-1″) |
| D – Head Tube Length | 210mm (8″) |
| E – Head Tube Angle | 69° |
| F – Seat Tube Angle | 70° |
| G – Rear Chainstay Length | 480mm (18″) |
| H – Front Wheel Center | 673mm (26″) |
| I – Wheelbase | 1151.5mm (45″) |
| J – Reach | 420mm (16″) |
| K – Stack Height | 520mm (20″) |
| L – Fork Length | 395mm (15″) |
| M – Fork Offset | 38mm (1″) |
| N – Trail | 63mm (2″) |
| Rider Height | 4’11” – 6’3″ |
Specs & Details
General Info
| Model | Abound SR Ebike |
| Weight | 80 lbs |
| Total Weight Limit | 440 lbs |
| Rider Height | 4’11” – 6’3″ |
| Ebike Class | Class 2 Ebike |
| Ideal Use | Cargo & Utility |
| Pedal Assist | 3 Levels (with Ride Tune Customization) |
| Safety Certifications | UL and TUV Safety Certified UL 2849 |
| Range | Up to 60 miles |
| Folding | No |
| Battery Safety Certifications | Certified to UL 2271 |
| Carry Capacity | Carry A Single Passenger |
| Water Resistance | Bike – IPX5 // Components – IPX6 |
Frameset
| Fork | Threaded Steerer Tube for Quill Stem 15×110 spacing, 50mm travel, adjustable lockout, black stanchions |
| Frame Style | Step-Through |
| Frame | 6061 Aluminum Alloy with Internal Battery. One piece – Diecast aluminum front triangle |
Wheelset
| Tires | 20 x 3.0 urban tire with reflective sidewalls |
| Wheels | 20-inch, 12-gauge, 36-hole, double-wall aluminum, black |
Ebike System
| Motor Torque | 80Nm |
| ECU | Aventon ECU Module featuring wired CAN communication, GPS positioning support, wireless Bluetooth connectivity, and cellular communication capabilities |
| Throttle | Aventon LH Handlebar Mounted |
| Sensors | Double Sided Bottom Bracket Torque Sensor |
| Charger | Aventon 4A 42V |
| Display | Aventon BC147 |
| Speed | Class 2 |
| Battery | Aventon 36V, 20Ah, 733Wh, LG 21700 cells |
| Motor | Shengyi 36V 750w Hub Drive with 6 speed sensors (1188W peak) |
Brakes
| Rear Brake Rotor | Tektro 203mm 6 bolt |
| Front Brake | Tektro HD-E3520 hydraulic disc brakes |
| Rear Brake | Tektro HD-E3520 hydraulic disc brakes |
| Front Brake Rotor | Tektro 180mm 6 bolt |
Drivetrain
| Chain | 122 Link, 8 Speed |
| Chainring | 52 tooth |
| Crank | 3pc, 165mm crank arm |
| Rear Derailleur | Shimano Altus RD-M310 8 Speed |
| Shift Lever | Shimano SL-M315-8R 8 Speed |
| Cassette | Shimano CS-HG200-8 8 speed Cassette, 12-32T |
| Pedals | 9/16″ Composite Platform |
| Chainring BCD | 130 |
Cockpit
| Saddle | Aventon by SelleRoyal |
| Seatpost | 30.9mm Aventon Suspension Seatpost with 50mm travel |
| Handlebars | BMX Style, 31.8mm bar clamp, 680mm width |
| Stem | Quill Stem with 31.8mm bar clamp diameter, 40mm length, and 140mm of vertical adjustment |
| Seat Clamp | 34.9mm Quick Release |
| Grips | Lock-on ergonomic |
Included Accessories
| Rear Rack | Included |
| Kickstand | Included: E-lock |
| Rear Wheel Mesh Guards | Included |
| Rear Rack Weight Limit | 143 lbs |
