TOP SPEED
28 MPH
RANGE
UP-TO 31–93 miles
MOTOR POWER
250W Peak
PAYLOAD
300 lbs
FOLDABLE
Not Foldable
BRAND WARRANTY
5-year frame warranty
Frame Geometry
| Measurement |
41 cm |
44 cm |
48 cm |
54 cm |
| A. Seat Tube Length |
410 mm |
440 mm |
480 mm |
540 mm |
| B. Top Tube Length |
605 mm |
615 mm |
635 mm |
660 mm |
| C. Chain Stay Length |
450 mm |
450 mm |
450 mm |
450 mm |
| D. Bottom Bracket Offset |
60 mm |
60 mm |
60 mm |
60 mm |
| α. Head Tube Angle |
66.5° |
66.5° |
66.5° |
66.5° |
| β. Seat Tube Angle |
73.5° |
73.5° |
73.5° |
73.5° |
| Wheelbase |
1176 mm |
1186 mm |
1206 mm |
1233 mm |
| Reach |
401 mm |
411 mm |
431 mm |
451 mm |
| Stack |
688 mm |
688 mm |
688 mm |
688 mm |
Specifications
Drive System
| Drive Unit |
Bosch Performance Speed, Smart System |
| Battery |
Bosch PowerTube 750 Wh Smart System |
Charging
| Charger |
Bosch Smart System 4A |
| Charging Time |
Approx. 6 hours |
Electronics
| Display |
Bosch Purion 200 |
| System |
Bosch Smart System |
| Motor Type |
Bosch Performance Speed mid-drive |
| Battery Type |
Bosch PowerTube integrated battery |
| Battery Capacity |
750 Wh |
| Charging Interface |
Bosch Smart System charger |
| Assist Modes |
Multiple Bosch assist levels |
| Controller |
Bosch Purion control interface |
| Connectivity |
Bosch Smart System connectivity |
| Firmware |
Updatable Bosch Smart System firmware |
| Integration |
Fully integrated Bosch ecosystem |
Frameset
Frame and suspension components
| Frame |
Aluminum 6061 |
| Fork |
Suntour Lytro-34 Air Boost LOR DS 15LH-110 29″ CTS |
| Rear Shock |
N/A |
| Frame Type |
Hardtail aluminum frame |
Drivetrain
| Derailleur |
Shimano Deore RD-U6000-GS |
| Gears |
10-speed |
| Crankset |
Samox EMS05-BHV04-NS40T-C53 + P33-38T |
| Cassette |
Shimano CS-M4100-10, 11-46T |
| Gear Range |
Wide range cassette for versatile riding |
| Drivetrain Type |
Shimano 10-speed drivetrain |
Brake
| Front Brake |
Shimano BR-MT200, 203 mm, Center Lock + Lock Ring |
| Rear Brake |
Shimano BR-MT200, 180 mm, Center Lock + Lock Ring |
| Brake Type |
Hydraulic disc brake system |
| Brake Performance |
Reliable hydraulic braking |
| Brake Material |
Aluminum alloy brake components |
| Safety |
High braking stability and control |
Wheel
| Front Hub |
Shimano HB-TC500-15-B, Center Lock, 110×15mm E-Thru, 14G×32H |
| Rear Hub |
Shimano FH-TC500-HM, Center Lock, 148×12mm E-Thru, 13G×32H |
Rims
| Rims |
BULLS DDM-12 (inner width 30mm), 29er / 27.5 Plus, 14G×32H |
| Valve Type |
F/V |
Tires
| Tires |
CST CC-03 Supero All Ground, 62-584 |
| Type |
All-terrain eBike tires |
Cockpit
| Handlebar |
BULLS, Width 680 mm, Rise 28 mm, 25° backsweep, Bore 31.8 |
| Stem |
BULLS Adjustable Stem, Ext 65 mm, Bore 31.8 mm |
Seat System
| Seatpost |
BULLS SP-F102, 7 mm Offset, 2-Bolt Type, 30.9 × 350 mm |
| Seat |
Selle Royal 4007HR0 |
Pedals
| Pedals |
Wellgo C-098DU |
| Type |
Platform pedals |
Weight
| Bike Weight |
58.4 lbs |
| Note |
*Specifications subject to change without notice |
