TOP SPEED
28 MPH
RANGE
UP-TO 95 miles
MOTOR POWER
750W Peak
PAYLOAD
440 lbs
FOLDABLE
Not Foldable
BRAND WARRANTY
2-year
One-Touch Class Switching
Easily switch between Class 1, 2, and 3 to match local regulations. Where permitted, Custom Mode unlocks Class 3 throttle speeds up to 28 mph.
SensorSwap™
With one click, switch between torque mode for precise control and cadence mode for smooth cruising.
Pulse Mode™
Train with intention using heart-rate-based assistance.
Smart Tuning
User profiles adjust power automatically, while Ride Tuning lets you fine-tune motor output and PAS.
Size Guide
| Measurement | Regular | Large |
|---|---|---|
| Recommended Rider Height | 5’2″ ~ 5’10” | 5’7″ ~ 6’5″ |
| Reach | 446 mm | 459 mm |
| Handlebar Height | 1000 mm | 1050 mm |
| Wheelbase | 1210 mm | 1224 mm |
| Stand-Over Height | 720 mm | 720 mm |
| Min Saddle Height | 790 mm | 830 mm |
| Max Saddle Height | 1000 mm | 1050 mm |
| Total Length | 1930 mm | 1943 mm |
Specifications
Size Guide
| Bike Size | Regular / Large |
| User Height Range | R: 5’2”~5’10” L: 5’7”~6’5” |
Frameset
| Frame | Triple-Butted Aluminum Alloy |
| Fork | RST Air Suspension 120mm Travel with Lock-out, Rebound Adjustable |
Electronics
| Motor | 48V, 750W (1300W Peak Power), 100Nm |
| Battery | 48V, 16.7Ah (801.6Wh), IPX7, Certificated by UL2271 |
| Cell | Samsung/LG 21700 cell, Certificated by UL2580 |
| Charger | 48V, 3A Fast Charger |
| Sensor | Torque and Cadence Sensor |
| Display | 2.0″ Left-mounted Full-color Display with High Brightness, Bluetooth, NFC |
| USB Port | USB Type-C phone Charge |
| Throttle | Trigger-control, Removable |
| Pedal Assist | 4 Riding Modes + Pulse Mode / Ride Tuning |
| Walk Mode | 2.9 MPH / Walk & Hold |
| Front Light | 500LM High-output Integrated LED, Adjustable Angle |
Lighting & Security
Integrated lighting and smart anti-theft features
| Rear Light | Brake highlight, Turn Signal |
| Water Resistant | IPX6 |
| Anti-theft | Apple Find My & Android Find Hub, NFC Card Unlock |
| Connectivity | Bluetooth & NFC |
Speed & Range
| Max Speed (Default) | 20 MPH |
| Max Speed Adjustable Range | 12~28 MPH |
| Ebike Class | Class 1 / 2 / 3 |
| Pedal Assist Range | 95 Miles |
| Throttle Range | 70 Miles |
| Range Note | Range may vary depending on rider weight, terrain, and assist level. |
Drivetrain
| Chainrings | BCD 104, 40T Narrow-Wide Chainring |
| Crankset | Aluminum Alloy, 165mm |
| Cassette | 9-speed, 11-46T |
Transmission
| Rear Derailleur | SHIMANO Cues, 9-speed |
| Shift Lever | SHIMANO Cues, 9-speed |
| Chain | KMC XGlide 9-speed |
Brake
| Brake | SHIMANO MT200 Hydraulic Disc Brake |
| Rotors | 180mm Front and Rear |
| Brake Levers | Aluminum Alloy with Power Cutoff |
| System | Hydraulic braking system |
| Safety | Motor power cut-off when braking |
| Performance | High-performance Shimano braking system |
Wheel
| Rims | Double-wall Aluminum Alloy |
| Front Hub | NOVATEC Aluminum Alloy, 15x110mm Thru-axle |
Tires
| Tire | Kenda 27.5×2.4″ MTB Puncture Resistant Tires |
| Type | MTB puncture-resistant tires |
Cockpit
| Handlebar | Aluminum Alloy, Φ31.8mm, 740mm |
| Grips | Durable Ergonomic Grips, Lockable |
Seat System
| Saddle | VELOTRIC Comfort Ergonomic Seat |
| Seatpost | Aluminum Alloy, φ31.6mm, 350mm |
Supports
| Fenders | Plastic, Front and Rear Full Coverage |
| Rear Rack | Optional |
Pedals
| Pedals | Plastic |
| Kickstand | Aluminum Alloy, Included, Rear Mount |
Weight & Load
| Bike Weight | 57 lbs |
| Rear Rack Load Capacity | 66 lbs |
Max Load
| Max Bike Load Capacity | 440 lbs |
| Weight Note | *Weight does not include fenders, kickstands, or pedals. |
Certification
| UL Certification | UL2849 & UL2271 |
| ISO Standard | ISO 4210 |
